Build your NAS based on Raspberry Pi 3/4 or Rock Pi 4  with up to 4 HDD/SSD and up to a capacity of 20TB. (depending on your setup)

Dual/Quad SATA HAT utilizes the dual USB3 bus on the Raspberry Pi 4

$25.00 Sold Out

Build your NAS based on Raspberry Pi 3/4 or Rock Pi 4  with up to 4 HDD/SSD and up to a capacity of 20TB. (depending on your setup)

Dual/Quad SATA HAT utilizes the dual USB3 bus on the Raspberry Pi 4

Features

  • up to 4x HDD/SSD´s - 2.5 or 3.5inch storage is supported
  • utilizes two independent USB3 buses on Raspberry Pi 4
  • 12V DC Type power input for powering 2.5inch drives and Raspberry Pi 4
  • External standard ATX power supply support for 3.5inch HDD´s
  • PWM Fan and heatsink for Raspberry Pi 4 CPU cooling
  • HDD suspend mode supported
  • UASP support
  • Software RAID 0/1/5 support
  • Optional Top board with PWM controlled fan for HDD heat dispatch, OLED display for IP address, storage and status information and function assignable switch

For 3.5inch HDD setups, a 12V 5A DC PS or standard ATX PSU is recommended to power the HDD´s and the Raspberry Pi. With 4x 3.5inch HDD´s the PSU should provide at least 60W or more.

 PLEASE NOTE: ! DOES NOT FIT THE PREVIOUS CASE KIT !

For 2.5inch HDD setups the 12V DC 4A power adapter ( >=30W power adapter ) is sufficient to power the disk drives and the Raspberry Pi 4 together.

It is important to mention that the power connector on the SATA HAT must be used to power up the NAS with Raspberry Pi 4.



Performance

The Quad SATA HAT utilizes two high performance JMS561 (one JMS561 for the Dual SATA HAT) and provides up to 400MB/s read/write performance with four disks in RAID0 mode.

 Product Content

Dual or Quad SATA HAT board
USB3.0 Connection adapter
Screws and brass bolts for mounting the HAT on top of the RASPI4
PWM controlled active heat-sink for the Raspi 4 CPU

 optional: SATA HAT Top Board



What you need to run this NAS?

For 2.5inch HDD operation

12V DC 4A/5A Power adapter
2.5inch HDD/SSD
Raspberry Pi 4 with OS running

For 3.5inch HDD operation

12V DC 5A or ATX PSU > 60W
3.5inch HDDs

SATA cables
Raspberry Pi 4 with OS running

 PLEASE NOTE: ! DOES NOT FIT THE PREVIOUS CASE KIT !



Penta SATA HAT for Rock Pi 4
New
translation missing: en.products.product.regular_price $49.00

Build your NAS based on Rock Pi 4 with up to 5 HDD/SSD and up to 100TB capacity

translation missing: en.products.product.regular_price $49.00

Build your NAS based on Rock Pi 4 with up to 5 HDD/SSD and up to 100TB capacity

The Penta SATA HAT utilizes the M.2/PCIe interface on Rock Pi 4 to provide up to 5 SATA ports. This HAT works only with Rock Pi 4 mounted on the heat sink.

The concept of 4 internal SATA and one eSATAp design was chosen because it makes the setup more flexible for the use of external disks.

Features

  • Up to 5x HDD/SSD, 2.5inch and 3.5inch storage is supported, max storage 100TB
  • 4x SATA
  • 1x eSATA with power
  • utilizes two lanes of the PCIe 2.1 bus on Rock Pi 4
  • DC power input with support for both 2.5inch drives and ROCK Pi 4
  • External standard ATX power supply support for 3.5inch HDD
  • HDD suspend mode support
  • Software RAID 0/1/5 support
  • Optional PWM control fan for HDD heat management
  • Optional OLED display for IP / Store information
  • PLEASE NOTE: You need to order the heat-sink with the Rock Pi 4 otherwise the Penta HAT can not be mounted on top!

eSATAp

To fully take advantage of the 5th SATA port, an eSATA connector was implemented which can be exported e.g. out of the case. The eSATA connector provides both data and power. It can directly drive a 3.5inch HDD via a single cable.

Performance

The Penta SATA HAT is powered by the JMB585 with 2 lanes 5Gbs PCIe buses with up to 10Gbps bandwidth. With 5 SSD's configured in Raid0 mode, speed of up to 803MB/s can be achieved.



Product Content

Penta SATA HAT board

M.2 interface board with high speed Ribbon connector cable


optional: SATA HAT Top Board



SATA HAT Top Board
New
translation missing: en.products.product.regular_price $9.00 Sold Out

For Dual/Quad and Penta SATA HAT

To monitor the SSD/HDD´s and display some basic information of the NAS, the TOP Board was designed.

translation missing: en.products.product.regular_price $9.00 Sold Out

For Dual/Quad and Penta SATA HAT

To monitor the SSD/HDD´s and display some basic information of the NAS, the TOP Board was designed.

It provides PWM FAN control, IP address info and other details via the implemented OLED display.

The select button can change the display content and as well power the device off. This button can also be assigned to custom functions on request via software settings.

A ribbon cable connects the SATA HAT with the Top board.

Product Content

SATA HAT Top board

Ribbon connector cable

ALLNET China Gift Cards
New

Shopping for someone else but not sure what to buy?

ALLNET China gift cards are the best choice when it comes to tech presents.

$10.00

Shopping for someone else but not sure what to buy?

ALLNET China gift cards are the best choice when it comes to tech presents.

Gift cards are delivered by email and contain instructions on how to redeem them at checkout.

Our gift cards have no additional processing fees and do not expire.

Internal SATA III Drive Enclosure
New
translation missing: en.products.product.regular_price $99.00 Sold Out

The perfect enclosure for your QUAD SATA / PENTA HAT build

translation missing: en.products.product.regular_price $99.00 Sold Out

The perfect enclosure for your QUAD SATA / PENTA HAT build

  • strong aluminum case
  • 5 drive bays for 2.5 and 3.5" disks
  • LED indicators for power and activity
  • hot swap-able drive bays
  • internal fan
  • mountable in e.g. computer case with 5.25" slots
  • strong back plane

Product dimensions: 22.5x 13x 15cm

Weight: 2.8kg

Note: you need an external e.g. ATX power supply to power the drives and the extension case fan

Rock Pi E Developers package
New
translation missing: en.products.product.regular_price $5.99

Rock Pi E based development made convenient!

translation missing: en.products.product.regular_price $5.99

Rock Pi E based development made convenient!

  • Board protection through acrylic cover
  • Easy access to all relevant parts of the board
  • includes GPIO extension pin header
  • cut out for easy removal and mount of the eMMC module
  • includes dual band antenna

Product content:

  • Acrylic cover with mounting screws and bolts
  • 40 pin GPIO extension pin header
  • 2.4/5GHz antenna kit with pigtail

Just add the Rock Pi E of your choice and you are ready to go!

ecoPI S housing for Rock Pi S
New
translation missing: en.products.product.regular_price $4.99

Protect and mount your Rock Pi S with this new functional case

translation missing: en.products.product.regular_price $4.99

Protect and mount your Rock Pi S with this new functional case

  • aluminum enclosure
  • enough height for GPIO based accessories
  • mounting holes for wall mount (optional bracket needed)
  • useful openings for all additional accessories e.g. antenna

Product content:

  • aluminum housing
  • screw kit

Options:

  • Dual band antenna kit
  • Wall mount bracket
USB-A OTG cable for e.g. Rock Pi E
New
translation missing: en.products.product.regular_price $2.99

Use the OTG feature via GPIO on Rock Pi E with this customized USB cable

translation missing: en.products.product.regular_price $2.99

Use the OTG feature via GPIO on Rock Pi E with this customized USB cable

Conversion of USB D+/D-/GND --> dupont (f) for convenient OTG access to Rock Pi E

green - D+ (Data+)

white - D-  (Data -)

black - GND

Rock Pi X - Heat Sink
New
translation missing: en.products.product.regular_price $9.99
Proper heat management for your Rock Pi X A / B boards
translation missing: en.products.product.regular_price $9.99
Proper heat management for your Rock Pi X A / B boards
ecoPI S housing for Rock Pi S - project version
New
translation missing: en.products.product.regular_price $4.99 Sold Out

Protect and mount your Rock Pi S

translation missing: en.products.product.regular_price $4.99 Sold Out

Protect and mount your Rock Pi S

  • aluminum enclosure
  • covered up SD card slot for protection
  • covered up reset and maskrom switch
  • only antenna, USB-C and LED indicator openings
  • mounting holes for wall mount (optional bracket needed)
  • enough height for GPIO based accessories

Product content:

  • aluminum housing
  • screw kit

Options:

  • Dual band antenna kit
  • Wall mount bracket
Rock Pi Model E heatsink kit
translation missing: en.products.product.regular_price $1.50

Properly cool CPU and RAM on your Rock Pi E

Set of 2 heat sinks with applied adhesive heat conduction tape

translation missing: en.products.product.regular_price $1.50

Properly cool CPU and RAM on your Rock Pi E

Set of 2 heat sinks with applied adhesive heat conduction tape

Heat sink for ROCK 3A
translation missing: en.products.product.regular_price $1.20

Optimal temperature levels even during peak CPU load

translation missing: en.products.product.regular_price $1.20

Optimal temperature levels even during peak CPU load

  • aluminum heat sink for CPU mount
  • high performance heat conductive tape
  • black color for best heat dissipation
  • height optimal for low profile cases

*pls note: can not be used with PoE hat
